GDM-8351 Dual Measurement Multimeter

RM2,594.00

Model: GDM-8351

GDM-8351
Ask a Question
PDF Icon

View
Datasheet

Key Specifications

  • 120,000 counts, VFD display
  • Dual measurement/Dual display
  • The basic precision of DC voltage: 0.012%
  • Selectable measurement speeds, the maximum: 320 Readings/s
  • True RMS (AC，AC+DC) measurements
  • Auto/manual selection
  • 12 different measurement functions: AC/DC voltage, AC/DC current, AC+DC voltage/current, 2W/4W resistance, continuity beeper, diode test, capacitance, frequency, temperature
  • Many auxiliary functions: Max./Min., REL/REL#, Compare, Hold, dB, dBm, Math (MX+B, %, 1/X)
  • Digital I/O provides dual mode (standard Compare and User definition modes)
  • Standard RS-232C and USB device interface (support USBCDC and USBTMC modes)

Description

GW Instek presents the brand new 5 1/2 Digit Dual Measurement Multimeter─ GDM-8351 to replace GDM-8251A of the same category. GDM-8351 features VFD dual-display, maximum 120,000 counts, 0.012% basic DC voltage accuracy and USB/RS232C connectors to provide users with measurement precision, lucid data observation, and the convenient connection with the personal computer.
